OUCO 2T10M Knuckle Boom Marine Deck Crane
Product Description
OUCO Marine/Offshore knuckle boom cranes are based on a pedestal slewing design with hydraulic cylinder luffing.
The boom extension is a knuckle inner section that allows a more flexible and wider operational radius in use and leaves the crane stored in a compact position.
The advantages of the knuckle cranes are low weight and less complex design making them maintenance-friendly.
The cranes are available from 5–40 meters of crane boom, which have long range of usage. OUCO Marine Knuckle cranes can be designed and manufactured by clients’ requirements in our own factory.
Product Feature
Hydraulic type makes the crane maintain easily.
Flexibility by extending booms.
Smaller ones take very limited space on the vessel/ship/shipyard.
Bigger ones can do heavy duty loads in several working conditions.
Technical Parameters
| SWL | 2T10M |
| Max. Working Radius | 10 m |
| Min. Working Radius | 2 m |
| Hoisting Speed | 0-20 m/min |
| Hoisting Height | 29 m |
| Slewing Speed | ~0.5 r/min |
| Slewing Angle | 360° |
| Luffing Time | ~120 s |
| Power | 2*315 kw+45 kw |
Product Details
FAQ
1. Q:Can this type work in hazardous environment?
A:Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Q:Can you provide the serious lifting tools?
A:Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q:How can we install the crane?
A:Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
